Disposable Cylinder Aluminum Non-Corrosive Regulator Model 3970HB 0-60 PSIG

Hover over image to zoom

  • Image 1
USD $165.00

 Product Description



DESCRIPTION
These compact regulators are designed to provide a constant fixed flow rate of non-corrosive gases and mixtures from disposable cylinders fitted with a CGA 600 outlet connection. They provide both pressure and flow control. When regulator is supplied without 1/4" flow control hose barb the 3970 is an adjustable pressure regulator.

FEATURES
• Adjustable delivery pressure.
• Integral needle valve for shut-off and to control flow.
• Integral CGA 600 connection provides compactness and minimal loss of gas during installation and removal.
• 0 - 300 psig inlet pressure gauge to monitor cylinder pressure.

SPECIFICATIONS
Inlet Pressure: 300 psig max.
Operating Temperature: 0° to 160°F
Inlet Connection: CGA 600
Outlet Connection:
1/4" hose barb with flow control orifice
Cylinder Pressure Gauge: 0-300 psig
Cv = 0.04

MATERIALS OF CONSTRUCTION
Body: aluminum
Piston: neoprene
Seat: neoprene
CGA gasket: composite cork
Gauge: stainless steel case, brass connection

HOW TO ORDER




Model No. Del. Press. Range
psig
Outlet

3970HB 0-60 1/4" hose barb with flow control orifice

TYPICAL LEAD-TIME 5-10 DAYS




SKU:
REG3970HB
Shipping:
Calculated at checkout
Minimum Purchase:
1 unit(s)
