Automatic Electric Gas Heaters Copper Tubes Model 1000-326 CGA 326 female x male (Nitrous Oxide, N20) Custom

Hover over image to zoom

  • Image 1
Competitor's Price: USD $3,050.00
USD $2,692.00 (You save USD $358.00)

 Product Description



DESCRIPTION
Many liquefied gases cool dramatically under even moderate flow conditions due to the heat of vaporization when the liquid is converted to gas. This effect causes "freezing" in pressure regulators and other equipment resulting in pressure and flow fluctuations. These thermostatically controlled heaters maintain a constant temperature within close limits regardless of load variations, thus assuring a uniform temperature and constant gas flow at all times. All units are completely automatic and can be left on indefinitely, even under no-flow conditions without damage.

APPLICATIONS
• Welding Operations
• Hospitals/Anesthegeology
• Bottling Plants/Wineries
• Foundries
• Food Packaging
• Semiconductor
• Gas Freeze-up Applications

FEATURES
• Prevents regulator freeze-up.
• Thermostatically controlled.
• Double protection against thermal or electrical overload.
• Continuous high pressure tubing –no internal joints.
• Working pressures up to 4600 psig.
• Completely dry - heat exchange medium is aluminum.
• Heavily insulated - cabinet remains "cool."
• Can be left on, even under no-flow conditions.
• Unlike ambient devices, not affected by adverse atmospheric conditions.
• Flow can be in either direction, without loss of efficiency.
• C.S.A. Approved.
• One Year Guarantee on Material & Workmanship.

SPECIFICATIONS

• 11" high x 5.5" wide x 4.25" deep
• 5/16" x .049 continuous copper tubing
• 5/16" x .049 304 stainless tubing optional
Working pressure: up to 2500 psig
• 11 lbs. actual weight; 13 lbs. shipping weight
• 6' 3-wire UL/CSA cord
• 120/240 volts A.C., single phase
• 8.3/4.2 (1000 watts)
• Mounting holes 3" on center



CAPACITY (FOR CARBON DIOXIDE, CO 2)**
• Heating : 1000 CFH; 17 CFM; 467 liters/minute; 115 lbs./hr. (Heating valves are based on initial gas temperature of 0°F and outlet temperature of 170°F)
• Vaporizing: 184CFH; 3 CFM; 84 liters/minute; 22 lbs./hr. (Vaporization valves are based upon initial liquid temperature of 0°F and outlet temperature of 170°F)
** Capacities for other gases will vary, depending on their specific heat.

HOW TO ORDER
1.   Select basic model
Model Number Description
1000-326 1000 watts, 120 volts A.C., copper tubes CGA 326 female x male (Nitrous Oxide, N20)

TYPICAL LEAD-TIME 5-7 DAYS
